數控花鍵磨床適用于磨削多種齒形的高精度直齒花鍵軸、滾珠花鍵、花鍵拉刀、塞規、滾軋輪及齒輪等零件。
It is available for grinding straight spline with various kinds of high precision profile, ball spline, plug gaugeroll wheel, gear and any parts with special profile.
該機主要用于磨削圓柱型、方型拉刀和螺旋拉刀的刃溝、后角、平面和溝等。配置功能部件可實現不同的加工要求，滿足客戶刃磨各類型拉刀的需求。
It is mainly available for grinding chip gullet circular, relief angle, surface, and slot of cylindrical and squaretype of broacher. Equipped with right accessories can achieve different machining requirements and satisfycustomer.
該機采用CBN成型砂輪磨削圓柱型拉刀、方形拉刀、前刃、后角、弧形和分屑槽。
The machine is used for cutting edge and back angle of cylindrical broach, square broach and spline broach(including l.C.P) grinding with CBN forming wheel.
數控成型磨床采用德國西門子系統，五軸全閉環控制，配置臺式修整器，將砂輪修整成型，對工件進行磨削加工。機床可廣泛用于航空、航天、工具、汽車、機床等行業的各類高精度復雜型面的磨削加工。
It is equipped with SlENENS control system, which is fully five axis close - loop controlled. Table dresser isused for profiling grinding wheel. Machine is widely employ in Aviation, Aerospace, Automobile, ToolsMachine tools industry for grinding variety of high precision profile.
|
